Disjoncteur à boîtier moulé UL489 NDM3EU-225

2024年3月13日Produit basse tension Produit lié aux énergies nouvelles UL489 MCCB13080

Certifications disponibles UL La disponibilité dépend du modèle et de la configuration.

Présentation générale

The UL489 NDM3EU-225 is an electronic molded-case circuit breaker developed for North American low-voltage distribution systems. It combines overload long-delay, short-circuit short-delay and instantaneous protection in a compact frame.

Disjoncteur à boîtier moulé UL489 NDM3EU-225

Avantages du produit

Electronic ProtectionAdjustable electronic functions coordinate overload and short-circuit protection.

UL ComplianceCertification supports use in North American distribution equipment and panels.

Flexible SettingsFrame ratings and trip settings can be matched to the protected feeder.

Practical IntegrationFixed, rear plug-in and lug-terminal arrangements support different panel designs.

Caractéristiques techniques types

Rated Insulation Voltage	800 V
Tension nominale	AC 240 / 480 V
Frame Current	Up to 225 A
Interrupting Capacity	65 kA at AC 240 V; 35 kA at AC 480 V
Mechanical / Electrical Life	4,000 / 4,000 operations
Certifications	UL 489, UL 486E, UL 1998

Configuration type uniquement. Les caractéristiques techniques définitives sont confirmées en fonction des exigences du projet.

Applications

Suitable for industrial switchboards, distribution panels and commercial power systems requiring electronic protection and UL-certified equipment.

LAST : NDB6AZ-125H 5G DC miniature circuit breakerSUIVANT : Norme IEC 60947-2 UL 489 NDB2T-63 3P

Recommandations connexes

NDM2-800
