Présentation générale
Panelboard – UL67, also known as a Low Voltage Distribution Panelboard, is an important low-voltage electrical distribution product used to distribute power from an upstream switchboard, switchgear, transformer, or main distribution panel to multiple branch circuits. It is commonly used in commercial buildings, residential buildings, industrial facilities, schools, hospitals, office buildings, public infrastructure, and other low-voltage power distribution systems.
Avantages du produit
Reliable Low-Voltage Final DistributionPanelboard – UL67 is designed to distribute low-voltage power to multiple final circuits.
Suitable for Lighting and Power DistributionThe product can be configured as a lighting panelboard or a power distribution panelboard.
Flexible Breaker ConfigurationThe panelboard can be equipped with molded case circuit breakers, miniature circuit breakers, or other branch protection devices according to system design.
Bolt-On and Plug-On OptionsDifferent breaker installation methods can be selected according to project requirements.
Caractéristiques techniques types
| Standard Reference | UL67-oriented design |
|---|---|
| Breaker Mounting | Bolt-on, rail-type bolt-on, plug-on, or plug-in options |
| Tension nominale | Low-voltage system, project-based configuration |
| Courant nominal | Customized according to project requirements |
| Protection Design | Branch circuit protection, overload protection, short-circuit protection |
| Enclosure Type | Wall-mounted or floor-mounted enclosure according to size and installation condition |
Configuration type uniquement. Les caractéristiques techniques définitives sont confirmées en fonction des exigences du projet.
Applications
Panelboard – UL67 is widely used in low-voltage electrical distribution systems where multiple branch circuits need to be protected, organized, and distributed. It is commonly installed downstream of transformers, LV switchgear, LV switchboards, or main distribution boards.
